| Business Type | Manufacturer, Exporter, Supplier |
| Usage | Commonly Used For Water Supply, Drainage, Irrigation, Gas Distribution |
| Color | Black |
| Material | High-Density Polyethylene (HDPE) |
| Click to view more | |
Product Details
Brand Name
Godfill
Size
20 mm to 630 mm
Length
6 Meters
Pressure Rating
Standard Pressure Ratings Of PN6, PN8, PN10, PN12.5, PN16
Temperature Rating
Up To 60 Degrees Celsius
Certified By
IS 4984:1995 certified
Grade
PE 100 grade resin
HDPE Pipe Wall Thickness — PN 6 (SDR 26)
| NOMINAL OD (MM) | MIN WALL THICKNESS (MM) | ID APPROX. (MM) | MASS (KG/M APPROX.) |
| 20 | 2 | 16 | 0.1 |
| 25 | 2 | 21 | 0.15 |
| 32 | 2 | 28 | 0.19 |
| 40 | 2 | 36 | 0.24 |
| 50 | 2 | 46 | 0.3 |
| 63 | 2.5 | 58 | 0.47 |
| 75 | 2.9 | 69.2 | 0.65 |
| 90 | 3.5 | 83 | 0.94 |
| 110 | 4.3 | 101.4 | 1.4 |
| 125 | 4.8 | 115.4 | 1.8 |
| 160 | 6.2 | 147.6 | 2.96 |
| 200 | 7.7 | 184.6 | 4.6 |
| 250 | 9.6 | 230.8 | 7.16 |
| 315 | 12.1 | 290.8 | 11.4 |
| 400 | 15.3 | 369.4 | 18.2 |
| 500 | 19.1 | 461.8 | 28.6 |
| 630 | 24.1 | 581.8 | 45.4 |
PN 6 (6 bar at 20°C). SDR 26.
HDPE Pipe Wall Thickness — PN 10 (SDR 17)
| NOMINAL OD (MM) | MIN WALL THICKNESS (MM) | ID APPROX. (MM) | MASS (KG/M APPROX.) |
| 20 | 2 | 16 | 0.12 |
| 25 | 2 | 21 | 0.18 |
| 32 | 2 | 28 | 0.23 |
| 40 | 2.4 | 35.2 | 0.35 |
| 50 | 3 | 44 | 0.55 |
| 63 | 3.8 | 55.4 | 0.87 |
| 75 | 4.5 | 66 | 1.23 |
| 90 | 5.4 | 79.2 | 1.76 |
| 110 | 6.6 | 96.8 | 2.63 |
| 125 | 7.4 | 110.2 | 3.39 |
| 160 | 9.5 | 141 | 5.56 |
| 200 | 11.9 | 176.2 | 8.69 |
| 250 | 14.8 | 220.4 | 13.5 |
| 315 | 18.7 | 277.6 | 21.4 |
| 400 | 23.7 | 352.6 | 34.5 |
| 500 | 29.7 | 440.6 | 54.1 |
| 630 | 37.4 | 555.2 | 85.7 |
PN 10 (10 bar at 20°C). SDR 17.
HDPE Pipe Wall Thickness — PN 16 (SDR 11)
| NOMINAL OD (MM) | MIN WALL THICKNESS (MM) | ID APPROX. (MM) | MASS (KG/M APPROX.) |
| 20 | 2 | 16 | 0.15 |
| 25 | 2.3 | 20.4 | 0.22 |
| 32 | 3 | 26 | 0.36 |
| 40 | 3.7 | 32.6 | 0.56 |
| 50 | 4.6 | 40.8 | 0.87 |
| 63 | 5.8 | 51.4 | 1.38 |
| 75 | 6.8 | 61.4 | 1.94 |
| 90 | 8.2 | 73.6 | 2.8 |
| 110 | 10 | 90 | 4.18 |
| 125 | 11.4 | 102.2 | 5.4 |
| 160 | 14.6 | 130.8 | 8.85 |
| 200 | 18.2 | 163.6 | 13.8 |
| 250 | 22.7 | 204.6 | 21.5 |
| 315 | 28.6 | 257.8 | 34.2 |
PN 16 (16 bar at 20°C). SDR 11.
