| Business Type | Manufacturer, Exporter, Supplier |
| Length | 10 Feet Or 20 Feet |
| Color | White |
| Material | PVC (Polyvinyl Chloride) |
| Click to view more | |
Product Details
Application
Irrigation, Water Supply, Drainage Systems
Type
PVC Pipes
Size
1/2 Inch To 12 Inches
Packaging
Usually Bundled In Packs Of 10 Or 20 Pipes
Pressure Rating
100 Psi To 300 Psi
Temperature Range
Suitable For Temperatures Ranging From 0°C To 60°C
UV Resistance
Resistant To UV Degradation
Brand Name
Godfill
We are a leading manufacturer, exporter, and supplier of high-quality Agricultural PVC Pipes designed for irrigation purposes. Available in lengths of 10 feet or 20 feet, these white PVC pipes are made from durable Polyvinyl Chloride material. Our PVC Pipes come in sizes ranging from 1/2 inch to 12 inches, with pressure ratings from 100 Psi to 300 Psi. They are UV resistant and suitable for temperatures ranging from 0°C to 60°C. Typically bundled in packs of 10 or 20 pipes, our PVC Pipes are reliable and efficient for agricultural applications.
Technical Specification
| NOMINAL OD (MM) | CLASS 1 (2.5 KGF/CM²) | CLASS 2 (4 KGF/CM²) | CLASS 3 (6 KGF/CM²) | CLASS 4 (8 KGF/CM²) | CLASS 5 (10 KGF/CM²) |
| 20 | — | — | — | — | 1.5 |
| 25 | — | — | — | — | 1.5 |
| 32 | — | — | — | 1.5 | 1.8 |
| 40 | — | — | — | 1.8 | 2.3 |
| 50 | — | — | 1.6 | 2.2 | 2.8 |
| 63 | — | 1.5 | 2 | 2.8 | 3.5 |
| 75 | — | 1.8 | 2.3 | 3.2 | 4.1 |
| 90 | — | 2.2 | 2.8 | 3.9 | 4.9 |
| 110 | 1.8 | 2.7 | 3.4 | 4.7 | 5.9 |
| 125 | 2 | 3.1 | 3.9 | 5.4 | 6.8 |
| 140 | 2.2 | 3.5 | 4.3 | 6 | 7.6 |
| 160 | 2.5 | 4 | 4.9 | 6.9 | 8.7 |
| 180 | 2.8 | 4.4 | 5.5 | 7.7 | 9.7 |
| 200 | 3.2 | 4.9 | 6.2 | 8.6 | 10.8 |
Wall thickness values are minimum per IS 4985:2000. Class 1 available from 110 mm OD. All dimensions in mm.
